HMAC-based Key Derivation Function (HKDF) RFC 5869 #

Hashed Message Authentication Code (HMAC)-based key derivation function (HKDF), can be used as a building block in various protocols and applications. The key derivation function (KDF) is intended to support a wide range of applications and requirements, and is conservative in its use of cryptographic hash functions. It is likely to have better security properties than KDF’s based on just a hash functions alone. See RFC 5869 for full detail. HKDF specifies a version of the NIST Special Publication 800-56C " Two-Step Key Derivation" scheme.

This is a standalone, lightweight, simple to use, fully tested and stable implementation in Java. The code is compiled with target Java 7 to be compatible with most Android versions as well as normal Java applications. It passes all test vectors from RFC 5869 Appendix A.

Quickstart #

Add dependency to your pom.xml (check latest release):

<dependency>
    <groupId>at.favre.lib</groupId>
    <artifactId>hkdf</artifactId>
    <version>{latest-version}</version>
</dependency>

A very simple example:

byte[] pseudoRandomKey = HKDF.fromHmacSha256().extract(null, lowEntropyInput);
byte[] outputKeyingMaterial = HKDF.fromHmacSha256().expand(pseudoRandomKey, null, 64);

Full Example #

This example creates a high-quality AES secret key and initialization vector from a shared secret calculated by a key agreement protocol and encrypts with CBC block mode:

//if no dynamic salt is available, a static salt is better than null
byte[] staticSalt32Byte = new byte[]{(byte) 0xDA, (byte) 0xAC, 0x3E, 0x10, 0x55, (byte) 0xB5, (byte) 0xF1, 0x3E, 0x53, (byte) 0xE4, 0x70, (byte) 0xA8, 0x77, 0x79, (byte) 0x8E, 0x0A, (byte) 0x89, (byte) 0xAE, (byte) 0x96, 0x5F, 0x19, 0x5D, 0x53, 0x62, 0x58, (byte) 0x84, 0x2C, 0x09, (byte) 0xAD, 0x6E, 0x20, (byte) 0xD4};

//example input
byte[] sharedSecret = ...;

HKDF hkdf = HKDF.fromHmacSha256();

//extract the "raw" data to create output with concentrated entropy
byte[] pseudoRandomKey = hkdf.extract(staticSalt32Byte, sharedSecret);

//create expanded bytes for e.g. AES secret key and IV
byte[] expandedAesKey = hkdf.expand(pseudoRandomKey, "aes-key".getBytes(StandardCharsets.UTF_8), 16);
byte[] expandedIv = hkdf.expand(pseudoRandomKey, "aes-iv".getBytes(StandardCharsets.UTF_8), 16);

//Example boilerplate encrypting a simple string with created key/iv
SecretKey key = new SecretKeySpec(expandedAesKey, "AES"); //AES-128 key
Cipher cipher = Cipher.getInstance("AES/CBC/PKCS5Padding");
cipher.init(Cipher.ENCRYPT_MODE, key, new IvParameterSpec(expandedIv));
byte[] encrypted = cipher.doFinal("my secret message".getBytes(StandardCharsets.UTF_8));

Note: HKDF is not suited for password-based key derivation, since it has no key stretching property. Use something like PBKDF2 or bcrpyt for that.

Using custom HMAC implementation #

//don't use md5, this is just an example
HKDF hkdfMd5 = HKDF.from(new HkdfMacFactory.Default("HmacMD5", 16, Security.getProvider("SunJCE")));

byte[] lowEntropyInput = new byte[]{0x62, 0x58, (byte) 0x84, 0x2C};
byte[] outputKeyingMaterial = hkdfMd5.extractAndExpand(null, lowEntropyInput null, 32);

Download #

The artifacts are deployed to jcenter and Maven Central.

Maven #

Add dependency to your pom.xml:

<dependency>
    <groupId>at.favre.lib</groupId>
    <artifactId>hkdf</artifactId>
    <version>{latest-version}</version>
</dependency>

Gradle #

Add to your build.gradle module dependencies:

compile group: 'at.favre.lib', name: 'hkdf', version: '{latest-version}'

Local Jar #

Grab jar from latest release.

Description #

For the full description see the RFC 5869. For an in-depth discussion about the security considerations see the Paper “Cryptographic Extraction and Key Derivation: The HKDF Scheme (2010)” by Hugo Krawczyk. The following is a summary of the 2 sources above. If there seems to be a contradiction, the original sources are always correct over this.

Extract and Expand #

HKDF follows the “extract-then-expand” paradigm, where the KDF logically consists of two modules.

1. To “extract” (condense/blend) entropy from a larger random source to provide a more uniformly unbiased and higher entropy but smaller output. This is done by utilising the diffusion properties of cryptographic MACs.
2. To “expand” the generated output of an already reasonably random input such as an existing shared key into a larger cryptographically independent output, thereby producing multiple keys deterministically from that initial shared key, so that the same process may produce those same secret keys safely on multiple devices, as long as the same inputs are utilised.

Note that some existing KDF specifications, such as NIST Special Publication 800-56A, NIST Special Publication 800-108 and IEEE Standard 1363a-2004, either only consider the second stage (expanding a pseudorandom key), or do not explicitly differentiate between the “extract” and “expand” stages, often resulting in design shortcomings. The goal of this HKDF is to accommodate a wide range of KDF requirements while minimizing the assumptions about the underlying hash function.

Use Cases #

HKDF is intended for use in a wide variety of KDF applications. Some applications will not be able to use HKDF “as-is” due to specific operational requirements. One significant example is the derivation of cryptographic keys from a source of low entropy, such as a user’s password. In the case of password-based KDFs, a main goal is to slow down dictionary attacks. HKDF naturally accommodates the use of salt; however, a slowing down mechanism is not part of this specification. Therefore, for a user’s password, other KDFs might be considered like: PKDF2, bcryt, scrypt or Argon2 which are all designed to be computationally intensive.

Key Derivation #

The following examples are from RFC5869 Section 4:

• The derivation of cryptographic keys from a shared Diffie-Hellman value in a key-agreement protocol.
• The derivation of symmetric keys from a hybrid public-key encryption scheme.
• Key derivation for key-wrapping mechanisms.

Creating multiple keys from a single input #

The expand phase includes an “info” parameter which should be used to create multiple key material from a single PRK source. For example a Secret Key and IV from a shared Diffie-Hellman Value.

Pseudorandom number generator (PRNG) #

These two functions may also be combined and used to form a PRNG to improve a random number generator’s potentially-biased output, as well as protect it from analysis and help defend the random number generation from malicious inputs.

Security Relevant Information #

OWASP Dependency Check #

This project uses the OWASP Dependency-Check which is a utility that identifies project dependencies and checks if there are any known, publicly disclosed, vulnerabilities against a NIST database. The build will fail if any issue is found.

Digital Signatures #

Signed Jar #

The provided JARs in the Github release page are signed with my private key:

CN=Patrick Favre-Bulle, OU=Private, O=PF Github Open Source, L=Vienna, ST=Vienna, C=AT
Validity: Thu Sep 07 16:40:57 SGT 2017 to: Fri Feb 10 16:40:57 SGT 2034
SHA1: 06:DE:F2:C5:F7:BC:0C:11:ED:35:E2:0F:B1:9F:78:99:0F:BE:43:C4
SHA256: 2B:65:33:B0:1C:0D:2A:69:4E:2D:53:8F:29:D5:6C:D6:87:AF:06:42:1F:1A:EE:B3:3C:E0:6D:0B:65:A1:AA:88

Use the jarsigner tool (found in your $JAVA_HOME/bin folder) folder to verify.

Signed Commits #

All tags and commits by me are signed with git with my private key:

GPG key ID: 4FDF85343912A3AB
Fingerprint: 2FB392FB05158589B767960C4FDF85343912A3AB

Build #

Jar Sign #

If you want to jar sign you need to provide a file keystore.jks in the root folder with the correct credentials set in environment variables ( OPENSOURCE_PROJECTS_KS_PW and OPENSOURCE_PROJECTS_KEY_PW); alias is set as pfopensource.

If you want to skip jar signing just change the skip configuration in the pom.xml jar sign plugin to true:

<skip>true</skip>

Build with Maven #

Use the Maven wrapper to create a jar including all dependencies

mvnw clean install

Checkstyle Config File #

This project uses my common-parent which centralized a lot of the plugin versions aswell as providing the checkstyle config rules. Specifically they are maintained in checkstyle-config. Locally the files will be copied after you mvnw install into your target folder and is called target/checkstyle-checker.xml. So if you use a plugin for your IDE, use this file as your local configuration.

Tech Stack #

• Java 7 (+ errorprone static analyzer)
• Maven

HKDF Implementations in Java #

• Mozilla: sync-crypto
• WhisperSystems: libsignal-protocol-java
• Square: keywhiz
• Bouncy Castle
• Google Tink

Related Libraries #

• BCyrpt Password Hash Function (Java)
• Single Step KDF [NIST SP 800-56C] (Java)
